零部件雙槽超聲波清洗機主要用于清洗油缸小零件等設備，配備兩個超聲波清洗槽。兩個清洗槽可單獨使用，也可分清洗和漂洗，自動化程度高，操作簡單。下面，我們具體了解下零部件雙槽超聲波清洗機設備。

The parts double groove ultrasonic cleaning machine is mainly used to clean equipment such as oil cylinder and small parts, and is equipped with two ultrasonic cleaning grooves. The two cleaning tanks can be used alone or divided into cleaning and rinsing, with high degree of automation and simple operation. Next, let's learn more about the parts and components of the double groove ultrasonic cleaning machine.

零部件雙槽超聲波清洗機清洗工藝流程：

Cleaning process flow of double groove ultrasonic cleaning machine for parts:

手動上料至進料平臺-平移至清洗槽架-料架下降-超聲波清洗-料架上升-轉換到?jīng)_洗槽架- 材料架降低- 超聲波沖洗- 材料架升高-平移到卸料和排空平臺-手動卸料

Manual feeding to feeding platform - translation to cleaning tank rack - lowering of material rack - Ultrasonic Cleaning - raising of material rack - conversion to flushing tank rack - lowering of material rack - Ultrasonic flushing - raising of material rack - translation to unloading and emptying platform - manual unloading

雙槽超聲波清洗機主要技術參數

Main technical parameters of double tank ultrasonic cleaning machine

1、清洗材料：液壓配件

1. Cleaning material: hydraulic accessories

2、藍筐尺寸：800600100mm

2. Blue basket size: 800600100mm

3、裝載重量：300公斤

3. Loading weight: 300kg

4、清洗介質：水+清洗劑/煤油

4. Cleaning medium: water + cleaning agent / kerosene

在超聲波清洗槽的兩側，有帶水槽的滾輪，用于對料筐進行排水和緩沖。

On both sides of the ultrasonic cleaning tank, there are rollers with water tanks for draining and buffering the material basket.

在漂洗過程中，將材料裝入清洗站，以確保兩個站都在工作。

During rinsing, the material is loaded into the cleaning station to ensure that both stations are working.

提高清潔效率。

Improve cleaning efficiency.

漂洗采用煤油清洗，漂洗還起到了工件的抗氧化作用，達到了兩個目的。

The rinsing adopts kerosene for cleaning, and the rinsing also plays an antioxidant role in the workpiece, achieving two purposes.

零部件雙槽超聲波清洗機水循環工藝：

Water circulation process of double tank ultrasonic cleaning machine for parts:

整個水循環處理系統在超聲波水箱和輔助水箱之間切換，不排放。只有當水不能用時，才通過排水管排到污水中，然后換干凈的水。換水周期大約3-5天，視使用情況而定，視頻率和清潔度而定片的。水循環系統由主水箱、副水箱、過濾泵、精濾器、循環管、進水排水閥和總排水管組成。

The whole water circulation treatment system switches between ultrasonic water tank and auxiliary water tank without discharge. Only when the water cannot be used, it is discharged into the sewage through the drainage pipe, and then replaced with clean water. The water change cycle is about 3-5 days, depending on the use, video rate and cleanliness. The water circulation system is composed of main water tank, auxiliary water tank, filter pump, fine filter, circulation pipe, water inlet and drainage valve and main drainage pipe.
